FW-S560 Thermal Imaging Monocular with 35mm Focal Distance 1024*768 OLED Display and IP67 Waterproof for 1000m Detection

Name: FWS560 Thermal Imaging Monocular with 35mm Focal Distance 1024768 OLED Display and IP67 Waterproof for 1000m Detection
Brand: Forward
Price: 1 USD

Brand Name : Forward

Model Number : FW-S560

Place of Origin : China

MOQ : 1 set

Payment Terms : L/C,T/T

Supply Ability : 100 pcs/year

Delivery Time : 5-8 work days

Detection Type : Vanadium Oxide Uncooled Focal Plane

NETD : ≤40mk@F1.0

Focal distance : 35mm

Display : 1024*768 OLED

Contact Now

Features of FW-S560 Thermal imaging night vision device

384*288 Vanadium Oxide Uncooled Focal Plane
High resolution 1024*768 OLED
Small size, light weight, can be handheld for observation and operation
IP67 waterproof and dustproof

Specifications of FW-S560 Thermal imaging night vision device

Detector Type	Vanadium Oxide Uncooled Focal Plane
Resolution	384*288
Pixel spacing	17μm
NETD	≤40mk@25℃
Focal distance	35mm
FOV	10,7°*8.0°
Image mode	White hot, black hot
Focus	Manual focus
Display	0.6inch,color OLED,resolution1024*768
Electronic zoom	X2,X4
MRTD	≤0.6℃
Protection level	IP67
Battery operating time	≧3h
Woking Temperature	-40℃~+60℃
Storage temperature	-40℃~+70℃
Weight	≤0.6kg
Size	210mm100mm115mm
Detection distance	Pepole 1.8m*0.5m 1000m
Detection distance	Car 2.3m*2.3m 1500m
Identification distance	Pepole 1.8m*0.5m 500m
Identification distance	Car 2.3m*2.3m 790m
